    Sharp LQ150X1LW95 15 Inch Industrial TFT Display 1024*768 Dots A-Si 400 Cd/M2 Brightness

    Ask Lasest Price
    Brand Name : Sharp
    Model Number : LQ150X1LW95
    Certification : ROHS , REACH , ISO9001 , ISO14001
    Price : Negotiated
    Payment Terms : T/T, Paypal
    Supply Ability : More than 100000 pieces per month
    Delivery Time : Within 7 working days
    • Product Details
    • Company Profile

    Sharp LQ150X1LW95 15 Inch Industrial TFT Display 1024*768 Dots A-Si 400 Cd/M2 Brightness

    Industrial TFT Display, Sharp LQ150X1LW95 15 Inch 1024*768 Dots A-Si TFT LCD Display Module 400 Cd/M2 Brightness
    Sharp LQ150X1LW95 15 Inch 1024*768 Dots Industrial TFT Display Key Specifications Special Features
    Panel Size:15 InchPanel Brand:Sharp
    Resolution:1024(RGB)×768, XGA, 85PPIBest View On:Symmetry
    Outline Dimension:326.5(W)×253.5(H) ×10.1(D) MmActive Area Size:304.128(W)×228.096(H) Mm
    Brightness:400 Cd/m² (Typ.)Contrast Ratio:1500 : 1 (Typ.)
    Operating Temp.:-20 ~ 70 °CStorage Temp.:-25 ~ 70 °C
    • Sharp Corporation (hereafter called Sharp) LQ150X1LW95 is a 15.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, With LED Driver , without touch screen.
    • It features an operating temperature range of -20 ~ 70°C , a storage temperature range of -25 ~ 70°C , and the maximal vibration level of 1.0G (9.8 m/s²).
    • It's general features are summarized in the following: WLED Backlight, Life ≥ 70K hours, With LED Driver, 180° Reverse, 6/8 bit, Matte .
    • Based on its features,we recommend that this model be applied to Industrial, Medical Imaging etc.
    Panel Brand Sharp
    Panel Model LQ150X1LW95
    Panel Size 15.0"
    Panel Type a-Si TFT-LCD , LCM
    Resolution 1024(RGB)×768, XGA, 85PPI
    Pixel Format RGB Vertical Stripe
    Display Area 304.128(W)×228.096(H) mm
    Bezel Opening 307.4(W)×231.3(H) mm
    Outline Size 326.5(W)×253.5(H) ×10.1(D) mm
    Surface Antiglare (Haze 25%), Hard coating (3H)
    Brightness 400 cd/m² (Typ.)
    Contrast Ratio 1500:1 (Typ.) (TM)
    Viewing Angle 85/85/85/85 (Typ.)(CR≥10) Left / Right / Up / Down
    Display Mode ASV, Normally Black, Transmissive
    Best View on Symmetry
    Response Time 35 (Typ.)(Tr+Td)
    Display Colors 262K/16.2M 70% NTSC
    Lamp Type WLED , 70K hours , With LED Driver
    Frequency 60Hz
    Touch Screen Without
    Panel Weight 950g (Max.)
    Application Industrial , Medical Imaging
    Signal Interface LVDS (1 ch, 6/8-bit) , 20 pins Connector
    Input Voltage 3.3V (Typ.)
    Environment Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -25 ~ 70 °C

    Sharp LQ150X1LW95 15 Inch 1024*768 Dots Industrial TFT Display Applications


    Digital products, POS machine, instrument & meter, automobile electronics, communication machine, medical machine, security machine, household electrical appliances and others


    Sharp LQ150X1LW95 15 Inch 1024*768 Dots Industrial TFT Display Packing term


    Protect product with polyfoam and multi layer paper board.

    Special protect carton for exporting product,

    Per customer requirement.


    Sharp LQ150X1LW95 15 Inch 1024*768 Dots Industrial TFT Display Delivery term


    For samples, we will finish production and ship within 7~15 working days. We usually arrange DHL, UPS, FedEx express to ship samples.

    For bulk orders, usually 25~35 working days and depends on your design. For bulk orders, we support shipping by air or by sea as per customers' requirements.


    Custom design OEM/ODM solutions


    We support both standard and customized products and can put your logo on the products. Our experienced R&D team will support technical questions. ODM/OEM products are warmly welcome.


    Our Advantages


    Prompt reply within 12 hours.

    Products with top quality.

    Very competitive prices.

    Small MOQ accepted.

    More than 10 years’ experience in LCD R&D and manufacturing.

    Strong R&D term supports perfect customized projects.

    Fabulous after-sale service.


    Sharp LQ150X1LW95 15 Inch 1024*768 Dots Industrial TFT Display Mechanical Drawing
