    7.0 Inch TFT LCD Display Module, 1024x600Dots, 50 Pin RGB Interface, Capactive Touch Panel

    Ask Lasest Price
    Brand Name : ZP
    Model Number : ZP70100
    Certification : ROHS , REACH , ISO9001 , ISO14001
    Price : Negotiated
    Payment Terms : T/T, Paypal
    Supply Ability : More than 100000 pieces per month
    Delivery Time : Within 7 working days
    • Product Details
    • Company Profile

    7.0 Inch TFT LCD Display Module, 1024x600Dots, 50 Pin RGB Interface, Capactive Touch Panel

    TFT LCD Display Module 7.0 Inch 1024x600Dots 50 Pin RGB Inerface With Capactive Touch Panel
    ZP70030 is a transmissive type a-Si TFT LCD Display module , which is composed of a TFT-LCD panel , a driver circuit and a backlight unit . The panel size is 7.0 inch and the resolution is 800 ( RGB ) x 480 , the panel can display up to 16 M colors . The LCM can be easily accessed by micro-controller via parallel interface .
    TFT LCD Display Key Specifications / Special Features :
    Display Size7.0 InchResolution1024 ( RGB ) X 600
    Outline Dimension164.90 x 100.00 x 5.20 mmInterface24 Bit RGB
    Operating Temperature-20 To 70 ℃Viewing Direction6 O'clock
    Storage Temperature-30 To 80 ℃Touch PanelWith Resitive Touch Panel

    Active area

    154.08 x 85.92 mm

    Driver IC

    ST5623 & ST5091

    Contrast ratio

    600 : 1

    Storage Temperature

    -30 To 80 ℃

    Viewing angle

    70 / 70 / 60 / 60

    Backlight

    White LED x 18

    Current90 mAFPC Connector50 pin

    LCD Display Module Applications


    Digital products , POS machine , instrument & meter , automobile electronics , communication machine , medical machine , security machine , household electrical appliances and others .


    Packing term


    Protect product with polyfoam and multi layer paper board .

    Special protect carton for exporting product .

    Per customer requirement .


    TFT LCD Display Module Delivery term


    For samples , we will finish production and ship within 7 working days . We usually arrange DHL , UPS , FedEx express to ship samples .

    For bulk orders , usually 30 working days and depends on your design . For bulk orders, we support shipping by air or by sea as per customers' requirements .


    Custom design OEM/ODM solutions


    We support both standard and customized products and can put your logo on the products . Our experienced R&D team will support technical questions . ODM/OEM products are warmly welcome .


    Our Advantages


    Prompt reply within 12 hours .

    Products with top quality .

    Very competitive prices .

    Small MOQ accepted .

    More than 10 years’ experience in LCD R&D and manufacturing .

    Strong R&D term supports perfect customized projects .

    Fabulous after-sale service .


    TFT LCD Display Module 7.0 Inch Mechanical Drawing
